Automatic Sticker Labelling Machine – For Ampoules

> >
Laxmi Pharma Equipment offers Automatic High Speed ampoule Sticker Labeling Machine Model: LASL series, Vertical Linear Sticker Labeling machine suitable for labeling glass ampoule which are previously filled and sealed. As the machine is servo or stepper motor operated, a customer has an added advantage to run the machine with a minimum required output to maximum of 250-300 Labels per minute but depending upon the Label Size and Quality. All the adjustments are completely user friendly and requires minimal tools.
Salient Features
  • No change parts are required for changeover of ampoule size.
  • Synchronized speed of Label Dispensing, Conveyor and Pressing Device.
  • Easy to change label application height.
  • Self protected against any voltage fluctuations.
  • Suitable for On-Line Ink Jet and Contact Coding System.
  • Suitable for Partial, Full Wrap Around and Overlap Labeling.
  • High Production Speed up to 300 ampoules/min.
  • PLC based system with touch screen HMI.
  • Conveyor & servo speed synchronized and controlled from HMI.
  • In built Speed Indicator & Counter.
  • There is no requirement of Oil or Grease for maintenance.
  • Online rejection system (if required).
Technical Specification
Model No. LASL 80 LASL 100 LASL 150 LASL 200
Label Height 10mm to 45mm 10mm to 90mm 10mm to 90mm 10mm to 90mm
Label Length 10-25mm 10-25mm 10-25mm 10-25mm
Gap Between two labels Minimum 3-5mm Minimum 3-5mm Minimum 3-5mm Minimum 3-5mm
Label Roll Dia. Standard Standard Standard Standard
Power Characteristics 220v, 1 Phase, 50Hz, 1.2kw 220v, 1 Phase, 50Hz, 1.2kw 220v, 1 Phase, 50Hz, 1.2kw 220v, 1 Phase, 50Hz, 1.2kw
Output / minute 60-80 labels/minute 80-100 labels/minute 140-150 labels/minute 180-200 labels/minute
Conveyor Length 1500 – 1800mm 1500 – 1800mm 1500 – 1800mm 1500 – 1800mm
